H1Z2Z2-K
ZHONGDE
-40℃~+90℃
AC 1.0/1.0KV; DC1.5KV
EN 50618
Characteristics of H1Z2Z2-K Double Insulation European Standard Abiding PV Cable:
Recognized File Number of TUV: R50370559
Temperature range for applications: -40℃~+90℃
Rated voltage: AC 1.0/1.0KV; DC1.5KV
Reference standard: EN 50618
Stranded tinned copper conductor
Insulation, Jacket: cross-linked materials
Fire performance:IEC60332-1
Smoke density: IEC 61034, EN 50268-2
Release of halogen acid gas: IEC 670754-1 N50267-2-1
Used in PV Systems
Characteristics of H1Z2Z2-K Double Insulation European Standard Abiding PV Cable:
Recognized File Number of TUV: R50370559
Temperature range for applications: -40℃~+90℃
Rated voltage: AC 1.0/1.0KV; DC1.5KV
Reference standard: EN 50618
Stranded tinned copper conductor
Insulation, Jacket: cross-linked materials
Fire performance:IEC60332-1
Smoke density: IEC 61034, EN 50268-2
Release of halogen acid gas: IEC 670754-1 N50267-2-1
Used in PV Systems
