UL1095 Hook-Up Wire

UL1095 Hook-Up Wire

80℃ Resilient Flexible High-quality Single Core Wire

产品说明 Product description
>额定温度：80℃ >额定电压：300V >参考标准：UL758,UL1581,CSAC22.2No.210.2 >导体使用单支或绞合30~16AWG 镀锡或裸铜 >PVC  绝缘，符合ROHS 环保标准 >通过ULWW-1、CSA    FT1及JQA-F-Mark  阻燃测试 >绝缘厚度均匀、易裁线、易剥皮 >用于一般电子、电器设备内部连接线				>Rated temperature:80℃      >Rated voltage:300V      >Reference standard:UL758,UL1581,CSAC22.2No.210.2      >Solid or stranded,tinned or bare copper conductor 30~16AWG      >PVC insulation,comply with ROHS environmental standard      >Passes UL WW-1,CSA FT1 and JQA-F-Mark flame test      >Uniform insulation thickness to ensure easy stripping and cutting      >For general purpose internal wiring of appliance
产品结构 Cable Construction
导体Conductor			绝缘Insulation			最大导体电阻 Max.COND.Resistance (Q/km,20℃,DC)	耐压强度 Dielectric strength (VAC,1min)
规格 AWG	构造(No./mm) Construction	外径(mm) DIA.	厚度(mm) Thickness		外径(mm) O.D.
30	1/0.254	0.25	0.33		0.90	361	2000
	7/0.10	0.30	0.32		0.95	381
28	1/0.32	0.32	0.34		1.00	227	2000
	7/0.127	0.38	0.34		1.05	239
	7/0.127 OS-1*	0.38	0.34		1.05	239
26	1/0.404	0.40	0.32		1.05	143	2000
	7/0.16	0.48	0.34		1.15	150
	7/0.16 OS-1*	0.48	0.34		1.15	150
24	1/0.511	0.51	0.34		1.20	89.3	2000
	11/0.16	0.61	0.32		1.25	94.2
	7/0.20 OS-1*	0.60	0.33		1.25	94.2
22	1/0.643	0.64	0.33		1.30	56.4	2000
	17/0.16	0.76	0.35		1.45	59.4
	7/0.254 OS-1*	0.76	0.35		1.45	59.4
20	1/0.813	0.81	0.34		1.50	35.2	2000
	26/0.16	0.94	0.33		1.60	36.7
	7/0.32 OS-1*	0.96	0.32		1.60	36.7
18	1/1.024	1.02	0.39		1.80	22.2	2000
	41/0.16	1.18	0.36		1.90	23.2
	7/0.404 OS-1*	1.20	0.35		1.90	23.2
16	1/1.29	1.29	0.36		2.00	14.0	2000
	26/0.254	1.49	0.38		2.25	14.6
备注.OS-1*:先镀后绞再镀铜线。Note.OS-1*:Over-coated tinned stranded copper.
