FLRYY
ZHONGDE
100℃
None
ISO 6722/ ISO 19642
FLRYY Automobile Cable With Jacket
产品说明 Product Description | ||||||||
| >额定温度：100℃ >参考标准：ISO 6722/ISO 19642 >导体使用绞合0.35~6.0mm² 裸铜 >PVC 绝缘，符合ROHS 环保标准 >PVC 护套，符合ROHS 环保标准 >通过ISO6722/ISO 19642阻燃测试 >使用标准绝缘厚度、易裁线、易剥皮 >用于汽车内部连接线 | >Rated temperature:100℃ >Reference standard:ISO6722/ISO 19642 >Stranded,bare copperconductor 0.35-6.0mm² >PVC insulation,comply with ROHS environmental standard >PVC jacket,comply with ROHS environmental standard >Passes ISO 6722/ISO 19642 flame test >Uniform insulation thickness to ensure easy stripping and cutting >For vehicleinternal wiring of appliance | |||||||
| 产品结构 Cable Construction | ||||||||
| 导体 Conductor | 绝缘 Insulation | 护套 Jacket | 最大导体电阻 Max.COND. Resistance (Q/km,20℃,DC) | |||||
| 面 积 Crosssection (mm) | 构造(No./mm) Construction | 外径(mm) DIA. | 芯数 (No.) | 厚度(mm) Thickness | 外径(mm) O.D. | 厚度(mm) Thickness | 外径(mm) 0.D. | |
| 0.35 | 12/0.20 | 0.80 | 2 | 0.25 | 1.30 | 0.50 | 3.60 | 55.5 |
| 3 | 0.25 | 1.30 | 0.50 | 3.80 | ||||
| 0.5 | 16/0.20 | 0.92 | 2 | 0.30 | 1.53 | 0.47 | 4.00 | 38.2 |
| 3 | 0.30 | 1.53 | 0.50 | 4.30 | ||||
| 0.75 | 24/0.20 | 1.13 | 2 | 0.34 | 1.80 | 0.50 | 4.60 | 25.4 |
| 3 | 0.34 | 1.80 | 0.51 | 4.90 | ||||
| 1.0 | 32/0.20 | 1.31 | 2 | 0.35 | 2.00 | 0.50 | 5.00 | 19.1 |
| 3 | 0.35 | 2.00 | 0.60 | 5.50 | ||||
| 1.5 | 30/0.25 | 1.58 | 2 | 0.36 | 2.30 | 0.60 | 5.80 | 13.0 |
| 3 | 0.36 | 2.30 | 0.62 | 6.20 | ||||
| 2.5 | 50/0.25 | 2.04 | 2 | 0.40 | 2.85 | 0.65 | 7.00 | 7.82 |
| 3 | 0.40 | 2.85 | 0.68 | 7.50 | ||||
| 4.0 | 56/0.30 | 2.59 | 2 | 0.48 | 3.55 | 0.75 | 8.60 | 4.85 |
| 3 | 0.48 | 3.55 | 0.77 | 9.20 | ||||
| 6.0 | 84/0.30 | 3.17 | 2 | 0.49 | 4.15 | 0.85 | 10.00 | 3.23 |
| 3 | 0.49 | 4.15 | 0.88 | 10.70 | ||||
