TXL
ZHONGDE
125℃
None
SAE J 1128
TXL Crosslink Polyolefin Wire With Thin-Wall Insulation
| 产品说明 Product description | ||||||
| >额定温度：125℃ >参考标准：SAEJ1128 >导体使用绞合24~8AWG 镀锡或裸铜 >FR-XLPE 绝缘，符合ROHS 环保标准 >通过SAEJ1128 阻燃测试 >使用标准绝缘厚度、易裁线、易剥皮 >用于汽车内部连接线 | >Rated temperature:125℃ >Reference standard:SAEJ1128 >Stranded,tinned or bare copper conductor 24~8AWG >FR-XLPE insulation,comply with ROHS environmental standard >Passes SAEJ1128 flame test >Uniform insulation thickness toensure easy stripping and cutting >For vehicle internal wiring of appliance | |||||
| 产品结构 Cable Construction | ||||||
| 导体Conductor | 绝缘Insulation | 耐压强度 Dielectric Strength (VAC,1min) | ||||
| 规格 AWG | 面积 Crosssection (mm²) | 构造(No./mm) Construction | 外径(mm) DIA. | 厚度(mm) Thickness | 外径(mm) 0.D. | |
| 24 | 0.22 | 7/0.20 | 0.60 | 0.42 | 1.45 | 1000 |
| 22 | 0.35 | 7/0.254 | 0.76 | 0.42 | 1.60 | 1000 |
| 20 | 0.50 | 7/0.31 | 0.93 | 0.44 | 1.80 | 1000 |
| 18 | 0.80 | 16/0.254 | 1.17 | 0.44 | 2.05 | 1000 |
| 16 | 1 | 26/0.254 | 1.49 | 0.43 | 2.35 | 1000 |
| 14 | 2 | 19/0.36 | 1.80 | 0.43 | 2.65 | 1000 |
| 12 | 3 | 19/0.45 | 2.25 | 0.48 | 3.20 | 1000 |
| 10 | 5 | 19/0.57 | 2.85 | 0.53 | 3.90 | 1000 |
| 8 | 8 | 19/0.71 | 3.55 | 0.63 | 4.80 | 1000 |
