GXL
ZHONGDE
100℃
SAE J 1128
GXL Crosslink Polyolefin Insulated Wire for General Use
General Purpose Tinned Copper Automotive Wire For Industry
| 产 品 说 明 Product Description | ||||||
| >额定温度：100℃ >参考标准：SAEJ1128 >导体使用绞合20-8AWG 镀锡或裸铜 >XLPE 绝缘，符合ROHS 环保标准 >通过SAEJ1128 阻燃测试 >使用标准绝缘厚度、易裁线、易剥皮 >用于汽车内部连接线 | >Rated temperature:100℃ >Reference standard:SAEJ1128 >Stranded,tinned or bare copper conductor 20~8AWG >XLPE insulation,comply with ROHS environmental standard >Passes SAE J1128 flame test >Uniform insulation thicknessto ensure easy stripping and cutting >For vehicle internal wiring of applance | |||||
| 产品结构 Cable Construction | ||||||
| 导体 Conductor | 绝缘 Insulation | 耐压强度 Dielectric Strength (VAC,1min) | ||||
| 规格 AWG | 面积 Crosssection (mm²) | 构造(No./mm) Construction | 外径(mm) DIA. | 厚度(mm) Thickness | 外径(mm) 0.D. | |
| 20 | 0.50 | 7/0.31 | 0.93 | 0.59 | 2.10 | 1000 |
| 18 | 0.80 | 16/0.254 | 1.17 | 0.62 | 2.40 | 1000 |
| 16 | 1 | 26/0.254 | 1.49 | 0.61 | 2.70 | 1000 |
| 14 | 2 | 19/0.36 | 1.80 | 0.60 | 3.00 | 1000 |
| 12 | 3 | 19/0.45 | 2.25 | 0.68 | 3.60 | 1000 |
| 10 | 5 | 19/0.57 | 2.85 | 0.88 | 4.60 | 1000 |
| 8 | 8 | 19/0.71 | 3.55 | 1.08 | 5.70 | 1000 |
