UL 21445 Halogen Free Computer Cable

Model:
UL 21445
Brand:
ZHONGDE
Rated temperature:
80℃
Rated voltage:
30V
Reference standard:
UL758, UL1581

Availability:



Inquire Add to Basket

Product Description

Halogen Free Direct Multi Conductor Wire

产品说明 Product Description
>额定温度：80℃ >额定电压：30V >参考标准： UL758,UL1581,CSAC22.2No.210.2 >导体使用单支或绞合30~18AWG >镀锡或裸铜PE 绝缘，符合ROHS 环保标准 >镀锡或裸铜编织屏蔽 >TPE 护套，符合ROHS 环保标准 >通过UL水平阻燃及CSA FT2阻燃测试 >使用标准绝缘厚度、易裁线、易剥皮 >用于电脑连接线						>Rated temperature:80℃ >Rated voltage:30V >Reference standard:UL758,UL1581,CSAC22.2No.210.2 >Solid or stranded,tinned or bare copper conductor 30~18AWG >PE insulation,comply with ROHS environmental standard >Tinned or bare copper wire braid shield >TPE jacket,comply with ROHS environmental standard >Passes UL Horizontal flame and CSA FT2 flame test >Uniform insulation thickness to ensure easy stripping and cutting >For computer wiring of appliance
产品结构 Cable Construction
导体Conductor				绝缘Insulation			屏蔽Shield	排流线Drain	编织Braid	护套Jacket		最大导体电阻 Max.COND. Resistance (Q/km,20℃,DC)
规格 AWG	构造 Constuction (No./mm)	外径(mm) DIA.	芯数 (No.)	绝缘厚度(mm) Insulation thickness	外径(mm) 0.D.		构造 Construction (No./mm)	构造 Construction (No./mm)	构造 Construction (No.No.mm)	护套厚度(mm) Jacket thickness	外径(mm O.D.	最大导体电阻 Max.COND. Resistance (Q/km,20℃,DC)
30	7/0.10	0.30	2	0.25	0.80		Al-mylar	7/0.10	16/4/0.10	0.60	3.30	381
			3	0.25	0.80		Al-mylar		16/4/0.10	0.64	3.50
			4	0.25	0.80		Al-mylar		16/4/0.10	0.63	3.70
			5	0.25	0.80		Al-mylar		16/5/0.10	0.67	4.00
			6	0.25	0.80		Al-mylar		16/5/0.10	0.65	4.20
			7	0.25	0.80		Al-mylar		16/5/0.10	0.65	4.20
			8	0.25	0.80		Al-mylar		16/5/0.10	0.68	4.50
28	7/0.127	0.38	2	0.26	0.90		Al-mylar	7/0.127	16/4/0.10	0.60	3.50	239
			3	0.26	0.90		Al-mylar		16/4/0.10	0.63	3.70
			4	0.26	0.90		Al-mylar		16/5/0.10	0.66	4.00
			5	0.26	0.90		Al-mylar		16/5/0.10	0.64	4.20
			6	0.26	0.90		Al-mylar		16/6/0.10	0.65	4.50
			7	0.26	0.90		Al-mylar		16/6/0.10	0.65	4.50
			8	0.26	0.90		Al-mylar		16/6/0.10	0.67	4.80
26	7/0.16	0.48	2	0.26	1.00		Al-mylar	7/0.16	16/5/0.10	0.60	3.70	150
			3	0.26	1.00		Al-mylar		16/5/0.10	0.62	3.90
			4	0.26	1.00		Al-mylar		16/5/0.10	0.64	4.20
			5	0.26	1.00		Al-mylar		16/6/0.10	0.65	4.50
			6	0.26	1.00		Al-mylar		16/6/0.10	0.65	4.80
			7	0.26	1.00		Al-mylar		16/6/0.10	0.65	4.80
			8	0.26	1.00		Al-mylar		16/6/0.10	0.65	5.10
24	11/0.16	0.61	2	0.25	1.10		Al-mylar	11/0.16	16/5/0.10	0.60	3.90	94.2
			3	0.25	1.10		Al-mylar		16/5/0.10	0.62	4.10
			4	0.25	1.10		Al-mylar		16/5/0.10	0.62	4.40
			5	0.25	1.10		Al-mylar		16/6/0.10	0.62	4.70
			6	0.25	1.10		Al-mylar		16/6/0.10	0.65	5.10
			7	0.25	1.10		Al-mylar		16/6/0.10	0.65	5.10
			8	0.25	1.10		Al-mylar		16/7/0.10	0.65	5.40
22	17/0.16	0.76	2	0.27	1.30		Al-mylar	17/0.16	16/6/0.10	0.60	4.30	59.4
			3	0.27	1.30		Al-mylar		16/6/0.10	0.60	4.50
			4	0.27	1.30		Al-mylar		16/6/0.10	0.63	4.90
			5	0.27	1.30		Al-mylar		16/7/0.10	0.65	5.30
			6	0.27	1.30		Al-mylar		16/7/0.10	0.65	5.70
			7	0.27	1.30		Al-mylar		16/7/0.10	0.65	5.70
			8	0.27	1.30		Al-mylar		16/8/0.10	0.66	6.10
20	26/0.16	0.94	2	0.28	1.50		Al-mylar	26/0.16	16/7/0.10	0.60	4.70	36.7
			3	0.28	1.50		Al-mylar		16/7/0.10	0.63	5.00
			4	0.28	1.50		Al-mylar		16/8/0.10	0.64	5.40
			5	0.28	1.50		Al-mylar		16/8/0.10	0.63	5.80
			6	0.28	1.50		Al-mylar		16/9/0.10	0.65	6.30
			7	0.28	1.50		Al-mylar		16/9/0.10	0.65	6.30
			8	0.28	1.50		Al-mylar		16/9/0.10	0.68	6.80
