UL2919 Low Voltage Computer Cable
Low-voltage PVC Multi Conductor Wire for Electronic Equipment
| 产品说明 Product description | |||||||||
| >额定温度：80℃ >额定电压：30V >参考标准：UL758,UL1581,CSAC22.2No.210.2 >PVC 绝缘，符合ROHS 环保标准 >导体使用单支或绞合最小40AWG >镀锡或裸铜编织屏蔽 >PVC 护套，符合ROHS 环保标准 >通过UL WW-1 、CSA FT1及JQA-F-Mark 阻燃测试 >使用标准绝缘厚度、易裁线、易剥皮 >用于电脑连接线 | >Rated temperature:80℃ >Rated voltage:30V >Reference standard:UL758,UL1581,CSAC22.2No.210.2 >Solid or stranded,tinned or bare copper conductor 40AWG min. >PVCinsulation,comply with ROHS environmental standard >Tinned or bare copper wirebraid shield >PVC jacket,comply with ROHS environmental standard >Passes ULWW-1,CSA FT1 and JQA-F-Mark flame test >Uniform insulation thickness to ensure easy stripping and cutting >For computer wiring of appliance | ||||||||
| 产品结构 Cable Construction | |||||||||
| 型号 Style | 芯线Core | 导体Conductor | 绝缘外径 Insulation O.D (mm) | 屏蔽 Shield | 护套厚度 Jacket thickness (mm) | 护套外径 Jacket O.D. (mm) | |||
| 芯数 (No.) | 规格 AWG | 规格 AWG | 构造Construction (No./mm) | ||||||
| 1+4 | 1 | 1792 | 28 | 7/0.127 | 2.40 | AL-MYLAR +DRAIN +BRAID | 0.84 | 6.10 | |
| 4 | 1061 | 24 | 7/0.20 | 1.10 | |||||
| 1+8 | 1 | 1792 | 28 | 7/0.127 | 2.40 | 0.85 | 6.80 | ||
| 8 | 1061 | 24 | 7/0.20 | 1.10 | |||||
| 3+4 | 3 | 1792 | 28 | 7/0.127 | 2.40 | 0.83 | 7.50 | ||
| 4 | 1061 | 24 | 7/0.20 | 1.10 | |||||
| 3+5 | 3 | 1792 | 28 | 7/0.127 | 2.40 | 0.83 | 7.70 | ||
| 5 | 1061 | 24 | 7/0.20 | 1.10 | |||||
| 3+6 | 3 | 1792 | 28 | 7/0.127 | 2.40 | 0.84 | 8.10 | ||
| 6 | 1061 | 24 | 7/0.20 | 1.10 | |||||
